NPTT225 Motor US Motor Neptune 2.25thp C-FaceVar-Spd 230v 48Y

The Neptune™ 2.25 Total Horsepower (THP) variable speed pool pump motor is a premium efficiency product that includes a fully integrated motor, control, and user interface (UI). The product gives you programming flexibility and exceptional speed range capability. It is also designed to communicate and operate with a variety of external system controls, in addition to the on-board User Interface.

FEATURES:

• Efficiency: 2.25THP 85% at 3450 RPM
• Enclosure: Finned Aluminum enclosure providing a Water Ingress Protection level of IPX5 for long field life in outdoor environmental conditions
• User Interface: Fully functional, easy to operate, capable of 90°, 180°, or 270° rotation
• Rotation: Counter-clockwise (viewing motor shaft)
• Low Temperature Monitor: Threshold temperature configurable in the UI
• Fully Integrated: Designed for simple “Drop-In” installation with no complex wiring
• Auxiliary Load Relay
• Capable of communicating with specific pool control systems via MODBUS RTU
• Capable of setting up to seven daily schedules
• Adjustable priming time & speed
• Menu keypad lockout
• Designed for quiet operation
• UL 1081 approved
